CCD 카메라

MQ003CG-CM

제이엠제이 0 134



  • Smallest dimensions: 26 x 26 x 24 mm, 26 grams
  • VGA at 500+ fps
  • With flat ribbon flex cable ideal for Embedded vision systems
  • USB3 Vision Compliant



Applications: In-situ optical inspection camera, fast process capturing, e.g. golf club swings, Intelligent Transportation Systems (ITS), Open road tolling and Traffic monitoring, Industrial Automation, Machine Vision facial Recognition, Motion Capture, Automotive crash testingOCR/ OCV, 3D scanning, Robotic Arms, Material and Life science Microscopy, Ophthalmology and Retinal imaging, Medical Imaging, Flat panel inspection, Dental, Kiosks, Security, Biometrics



VGA Color CMOS Camera with USB 3.0 Interface.

Check conditions for the model version with Angled connector.



Specifications:
ResolutionVGA 0.3 MP 648 × 488 pixels
Sensor typeCMOS RGB Bayer Matrix
Sensor modelCMOSIS CMV300
Sensor size1/3"
Sensor active area4.8 × 3.6 mm
Pixel size7.4 µm
Bits per pixel8, 10, 12
Dynamic range60 dB
Frame rates500+ fps
Image data interfaceUSB 3.0
Data I/OGPIO IN, OUT
Power requirements1.5 Watt
Lens mountC or CS Mount
Weight26 grams
Dimensions WxHxD26 x 26 x 25 mm
Operating environment50 °C
Customs tariff code8525.80 30 (EU) / 8525.80 40 (USA)
ECCNEAR99



 MQ013CG-ON

MQ013CG-ON
  • 1.3 MPix
  • 1/2" CMOS, Global Shutter
  • PYTHON1300 Color
  • 210 fps



 MQ003CG-CM-BRD

MQ003CG-CM-BRD
  • VGA
  • 1/3" CMOS, Global Shutter, Board level
  • Color, CMOSIS CMV300
  • 500+ fps





Comments

Hot
MQ003MG-CM
VGA 1/3" CMOS, Global Shutter CMOSIS CMV300 Monochrome 500+ fps
Now
MQ003CG-CM
VGA 1/3" CMOS, Global Shutter CMOSIS CMV300 Color 500+ fps
Hot
MQ013RG-E2
1.3 MPix 1/1.8" CMOS, Global Shutter EV76C661 Near Infrared (NIR) enhanced 60 fps
MQ013MG-ON
1.3 MPix 1/2" CMOS, Global Shutter PYTHON 1300 Monochrome 210 fps
Hot
MQ013CG-ON
1.3 MPix 1/2" CMOS, Global Shutter PYTHON1300 Color 210 fps
MQ013RG-ON
1.3 MPix 1/2" CMOS, Global Shutter PYTHON 1300 Near Infrared (NIR) 210 fps
MQ022MG-CM
2.2 MPix 2/3" CMOS, Global Shutter CMOSIS CMV2000 Monochrome 170 fps
MQ022CG-CM
2.2 MPix 2/3" CMOS, Global Shutter CMOSIS CMV2000 Color 170 fps
MQ022RG-CM
2.2 MPix 2/3" CMOS, Global Shutter CMOSIS CMV2000 Near Infrared (NIR) 170 fps
MQ042MG-CM
4.2 MPix 1" CMOS, Global Shutter CMOSIS CMV4000 Monochrome 90 fps
MQ042CG-CM
4.2 MPix 1" CMOS, Global Shutter CMOSIS CMV4000 Color 90 fps
MQ042RG-CM
4.2 MPix 1" CMOS, Global Shutter CMOSIS CMV4000 Near Infrared (NIR) 90 fps
MD028MU-SY
2.8 MPix 2/3" CCD Black and white Sony ICX674 USB 3.0 interface 57 fps
MD028CU-SY
2.8 MPix 2/3" CCD Color Sony ICX674 USB 3.0 interface 57 fps
MD061MU-SY
6.1 MPix 16mm CCD Black and white Sony ICX694 USB 3.0 interface 28 fps
MD061CU-SY
6.1 MPix 16mm CCD Color Sony ICX694 USB 3.0 interface 28 fps
